- Steel and cast iron construction
- Built for heavy wear and tear in professional workshops
- Cast iron tables planed for accuracy and continuity
- Easily adjusted rigid side fence, adjustable Shaw guards for rebating
- Separate feed drive motor, three phase options have two feed speeds
- Braked motor with conveniently located emergency stop switch
- Now fitted with Tersa knife blocks as standard
Depending on the specific location, we may in some cases be able to offer a cheaper delivery price. Please get in touch for details.
- Surface Capacity: 308mm
- Thicknessing Width: 308mm
- Thicknessing Depth: 230mm
- Rebate Depth: 16mm
- Surface Table Length: 1,500mm
- Infeed Table Length: 850mm
- Surface Table Height: 885mm
- Thicknessing Table Length: 600mm
- Thicknessing Table Length Over Extension Rollers: 1,000mm
- Cutterblock Diameter: 102mm
- Cutterblock Knives: 3 (Tersa System)
- Feed Roller Diameter: 51mm
- Feed Speeds:
- 3 Phase - 4.5 and 7m/min
- 1 Phase - 6m/min
- Fence Size: 750 x 120mm
- Cutter Block Motor:
- 3 Phase - 3.0kW
- 1 Phase - 2.2kW
- Seperate Feed Motor: 0.375kW
- Dust Extraction Oulet Diameter: 125mm
- Total Air Volume Required: 1,125cmh
| Width | 950mm |
| Height | 1,265mm |
| Length | 1,700mm |
| Weight | 390kg |
Fitted with Tersa Knife System as Standard
