- Machine stand made of welded steel guarantees high torsional rigidity and vibration-free working
- sanding unit can be swiveled up to 45 ° via lever for sanding straight and bevelled edges
- Oscillating sanding belt with separate gear motor for better sanding results
- Oscillation optionally switchable
- sanding sole with graphite coating for a longer service life of the sanding belt
- Height-adjustable additional table with suction for sanding radii
- Automatic compensation of belt length differences due to spring-loaded belt tension
Dimensions and weights
Length approx. 1720 mm
Width/depth approx. 700 mm
Height approx. 1030 mm
Weight approx. 180 kg
Drive output
Oscillation motor 0.25 kW
Electrical Data
Supply voltage 400 V
Mains frequency 50 Hz
Extraction port
Extraction port diameter 120/80 mm
Sanding machine
Sanding belt length 2600 mm
Sanding belt width 150 mm
Circumferential belt speed(s) 20 m/s
Sanding surface length 850 mm
Sanding surface width 200 mm
Work top(s)
Work table height adjustment 180 mm
Longitudinal table length 750 mm
Longitudinal table width 300 mm
Longitudinal table height adjustment 180 mm
Min. cross table height 740 mm
VPE 1
No details given.
