- Longitudinal and transverse table for mitres from 0 ° to 45 ° steplessly swiveling
- Horizontally and vertically usable sanding unit, thus wide range of application vertical sanding possible
- Abrasive belt quick-voltage
- Standard with cross table for contour sanding, swiveling up to 45 °
- Longitudinal table is height-adjustable by 110 mm for optimum utilization of the sanding belt width
- Incl. infinitely adjustable miter fence
- Graphite coating on the sanding sole for a higher sliding property of the sanding belt and longer service life
Dimensions and weights
Length approx. 1320 mm
Width/depth approx. 600 mm
Height approx. 1020 mm
Weight approx. 78 kg
Electrical Data
Supply voltage 230 V
Mains frequency 50 Hz
Extraction port
Extraction port diameter 100 mm
Sanding machine
Sanding belt length 2010 mm
Sanding belt width 152 mm
Circumferential belt speed(s) 11 m/s
Sanding surface length 823 mm
Sanding surface width 152 mm
Work top(s)
Work table height adjustment 100 mm
Longitudinal table length 783 mm
Longitudinal table width 221 mm
Longitudinal table height adjustment 80 mm
VPE 1
No details given.
