Speed of the cylindrical sanding roller infinitely adjustable via potentiometer
Feed speed infinitely adjustable via potentiometer
Stable construction for high sanding accuracy
Table extension at the infeed and outfeed
Simple height adjustment of the sanding unit via crank handle
Lateral sanding head holder removable for processing of wider workpieces
Easy replacement of the sanding paper
Closed base with cabinet system and storage compartment
Dimensions and weights
Length approx. 1070 mm
Width/depth approx. 1080 mm
Height approx. 1200 mm
Weight approx. 119 kg
Electrical Data
Feed motor output 80 W
Drive motor output 1.1 kW
Supply voltage 230 V
Mains frequency 50 Hz
Extraction port
Extraction port diameter 100 mm
Feed unit
Feed speed 0 - 3,5 m/min
Sanding machine
Sanding belt length 3280 mm
Sanding belt width 78 mm
Sanding surface width 555 mm
Max. sanding width 555 mm
Max. sanding height 80 mm
Work top(s)
Work table length 592 mm
Work table width 505 mm
Table height 695 mm
Workpiece
Min. height 5 mm
Max. height 80 mm
Min. length 160 mm
VPE 1
No details given.
