- Inclination of the saw blade from 0 to 45°, adjustable without tools
- Height adjustment of the saw blade via hand crank and scale
- Large aluminum rip fence with eccentric quick release, can be used as a miter fence as well
- Large, galvanized steel machine table
- Easy to move thanks to integrated chassis with two wheels and foldable transport handles</ li>
- Delivered unmounted
Circular saw unit
Max. cutting width with rip fence 290 mm
Saw blade angle 90 – 45 °
Max. cutting height 90° 83 mm
Max. cutting height 45° 60 mm
(Main) saw blade diameter 315 mm
(Main) saw blade speed 2800 min¯¹
Dimensions and weights
Length approx. 1600 mm
Width/depth approx. 600 mm
Height approx. 1050 mm
Weight approx. 53 kg
Electrical Data
Absorbed power drive motor 2,2 kW
Supply voltage 230 V
Mains frequency 50 Hz
Extraction port
Extraction port diameter bottom 100 mm
Saw blade protection extraction port diameter 35 mm
Sliding carriage and table
Table length 800 mm
Table width 550 mm
Work height 850 mm
VPE 1
