- Large machine table made of galvanized steel
- Standard table extension can also be mounted as table widening right
- Precise sawmill swing over hand wheel with scale
- Saw blade height adjustable via easy-to-reach hand wheel
- Precise cuts due to stable, double suspension of the sawing unit
- Rip fence allows the lining of boards, thicknaces, fiber and angle cuts
- Easily drivable through integrated landing gear and foldable transport handles
- For easy transport or space-saving storage table feet can be folded easily
Circular saw unit
Max. cutting width with rip fence 805 mm
Max. cross cut width left from saw blade 245 mm
Saw blade angle 90 – 45 °
Max. cutting height 90° 90 mm
Max. cutting height 45° 50
Max. cutting height -45° 50 mm
(Main) saw blade diameter 315 mm
(Main) saw blade speed 2800 min¯¹
Dimensions and weights
Length approx. 1350 mm
Width/depth approx. 1250 mm
Height approx. 1000 mm
Weight approx. 60 kg
Electrical Data
Absorbed power drive motor 2,2 kW
Total rated value 10.3 A
Supply voltage 230 V
Mains frequency 50 Hz
Extraction port
Extraction port diameter bottom 100 mm
Saw blade protection extraction port diameter 30 mm
Sliding carriage and table
Table length 800 mm
Table width 550 mm
Work height 850 mm
VPE 1
