- The torsion-resistant cast iron machine bed ensures smooth running and precision
- Tailstock and headstock are also made of sturdy gray cast iron
- Drive can be moved freely on the machine bed
- Tailstock with quick release lever and handwheel
- Tailstock standard with revolving center point
- Tailstock quill with bore for machining long workpieces
- The tailstock is easily and quickly clamped on the machine bed thanks to single lever clamping
- Variable speed regulation from 0 - 3,200 rpm in two speed levels: 0 - 1,200 and 0 - 3,200 rpm
- A digital display shows the currently selected speed
- Right-left rotation as standard
Max. turning diameter 460 mm
Speeds 0 – 3200 min¯¹
Speed stages 2
Speed control Electronically variable
Travel of tailstock sleeve 110 mm
VPE 1
Dimensions and weights
Length approx. 2060 mm
Width/depth approx. 500 mm
Height approx. 1200 mm
Weight approx. 189 kg
Electrical Data
Supply voltage 230 V
Mains frequency 50 Hz
No details given.
