- Variable speed regulation in three speed stages: 650 - 1430; 1240 - 2790; 1600 - 3800
- Integrated digital speed display
- Large turning diameter of 305 mm
- Machine bed made of torsion-free grey cast iron for smooth running and great precision
- The tailstock and headstock are made of stable grey cast iron
- Tailstock quill with bore hole for machining longer workpieces
- The tailstock is easily and quickly clamped on the machine bed thanks to single lever clamping
- Bed extension for 550 mm max. width available as accessory
Max. turning diameter 305 mm
Speeds 650 – 1430, 1240 – 2790, 1600 – 3800 min¯¹
Speed stages 3
Speed control Electronically variable
Travel of tailstock sleeve 55 mm
VPE 1
Dimensions and weights
Length approx. 900 mm
Width/depth approx. 340 mm
Height approx. 410 mm
Weight approx. 38 kg
Electrical Data
Motor power input 0.55 kW
Supply voltage 230 V
Mains frequency 50 Hz
No details given.
