- Machine bed made of torsion-resistant gray cast iron for smooth running and precision
- Headstock made of stable gray cast iron
- Spindle with high concentricity accuracy
- Three infinitely adjustable speed ranges
- Standard with right-left rotation
- Tailstock sleeve with through-hole for machining long workpieces
- Simple tailstock fixation via quick-release lever
- Tool rest easily adjustable
Max. turning diameter 355 mm
Speeds 250 – 720, 600 – 1700, 1200 – 3550 min¯¹
Speed stages 3
Speed control Electronically variable
Travel of tailstock sleeve 70 mm
VPE 1
Dimensions and weights
Length approx. 1055 mm
Width/depth approx. 560 mm
Height approx. 460 mm
Weight approx. 50 kg
Electrical Data
Motor power input 0,75 kW
Supply voltage 230 V
Mains frequency 50 Hz
