- Infinitely adjustable double mitre and tilt to the left
- Base plate and rotary table made of die-cast aluminium, at the same time compact, robust and easily transportable
- Laser projection on the workpiece for precise control of the cutting position
- Laterally extendable support aids for longer workpieces
- Double adjustable cross-cut depth limiter
- Pull function for extended cutting range
- Standard with hold-down clamp for safe workpiece locking
- Extraction connection for dust collection bag or connection of an external extraction system
Saw band speed 4500 min¯¹
Saw blade diameter 210 mm
Max. bevel angle range left 45 °
Max. mitre left 45 °
Max. mitre right 45 °
VPE 1
Cutting capacity
0° inclination / 0° mitre 220 x 70 mm
-45° inclination / 0° mitre 155 x 70 mm
0° inclination / -45° mitre 220 x 35 mm
-45° inclination / -45° mitre 155 x 35 mm
Dimensions and weights
Length approx. 650 mm
Width/depth approx. 450 mm
Height approx. 430 mm
Weight approx. 10.5 kg
Electrical Data
Main motor 1,5 kW
Supply voltage 230 V
Mains frequency 50 Hz
No details given.
