- With infinitely adjustable double mitre and double tilt as standard.
- Base plate and rotary table made of die-cast aluminium, at the same time compact, robust and easily transportable
- Laser projection on the workpiece for precise control of the cutting position
- Adjustable stop rails on the right and left side
- Laterally extendable support aids for longer workpieces
- 2-fold adjustable cross-cut depth limitation
- Pull function for extended cutting range
- Standard with hold-down clamp for safe workpiece locking
- Suction socket for dust collection bag or connection of an external suction unit
Saw band speed 5000 min
Saw blade diameter 255 mm
Max. bevel angle range left 45 °
Max. bevel angle range right 45 °
Max. mitre left 45 °
Max. mitre right 45 °
VPE 1
Cutting capacity
0° inclination / 0° mitre 315 x 90 mm
-45° inclination / 0° mitre 215 x 90 mm
+45° inclination / 0° mitre 215 x 90 mm
0° inclination / -45° mitre 315 x 40 mm
-45° inclination / -45° mitre 215 x 40 mm
+45° inclination / +45° mitre 215 x 40 mm
Dimensions and weights
Length approx. 900 mm
Width/depth approx. 550 mm
Height approx. 430 mm
Weight approx. 17 kg
Electrical Data
Main motor 1,8 kW
Supply voltage 230 V
Mains frequency 50 Hz
